Special Glue for Honeycomb Paperboard Line

Full-line honeycomb paperboard adhesive covering core-strip and facing/lamination grades. Core making about 10–200 m/min; face laminating about 4–30 m/min. Cold/hot press; slow to instant dry adjustable.

Special Glue for Honeycomb Paperboard Line — Image 1
1 / 2

Special Glue for Honeycomb Paperboard Line

Key Features

  • Covers core-strip and facing/lamination needs
  • Core-making speed about 10–200 m/min
  • Facing line speed about 4–30 m/min
  • Cold/hot press; elastic/rigid film options
  • Slow to instant dry adjustable
  • Use with or without heating
  • Moisture-resistant, anti-mildew, eco-friendly

Product Description

Xuegong special glue for honeycomb paperboard lines covers the full honeycomb industry and suits various honeycomb equipment for boards and finished products.

Grades: core-strip adhesive meets core-making start-up speeds of about 10–200 m/min; facing/lamination (compound, stacking) adhesive meets face-board speeds of about 4–30 m/min.

Available for cold-press and hot-press bonding; elastic and rigid film grades; slow-, fast-, quick-, and instant-dry options. Can run with or without heating — heating can be skipped at lower speeds, and heating clearly raises start-up speed when used.

Among the earliest supporting glues developed for China’s honeycomb paperboard industry and a preferred choice after continuous improvement. Key strengths: fast drying with adjustable speed; firm bonding; excellent moisture resistance with anti-corrosion and anti-mildew performance; easy viscosity control; low consumption and cost; natural, green, and readily degradable; smooth, clean board appearance.

Facing glue has two preparation routes. Before ordering, confirm whether the facing step adds starch. The water figures below apply only to honeycomb facing glue. Do not copy them onto core-strip glue, paper-tube glue, or corrugator glue.

Complete low-temperature facing powder is for plants that add water only, with no extra starch or filler: 25 kg of powder plus 30–40 kg of room-temperature water, about 1:1.2 to 1:1.6. Charge the water first, then the powder, and stir for about 30 minutes. Adjust viscosity by changing water inside that range. Less water dries faster; more water dries slower. Less water also raises viscosity, and the mix must still coat evenly on the facing machine. One bag yields about 55–65 kg of liquid glue. A quantified recipe below 30 kg of water is not confirmed. Do not drop below that range on your own.

Premium low-temperature facing powder is for plants that add their own starch and filler: 25 kg of powder plus 40–60 kg of room-temperature water. Step 1: charge water, add the powder, and stir about 20 minutes until lump-free. Step 2: in a second tank, charge water, add starch and filler, and stir until lump-free. Step 3: pump the first tank into the second and stir until lump-free before use. Starch type, filler type, and the kilograms of each must be confirmed before the trial. This is not the 1:2 corrugator-concentrate recipe.

Technical Specifications

AppearanceWhite or slightly yellowish powder
OdorNo abnormal odor
Fineness (80 mesh)≥95.0%
Bond Strength (room temp)≥5.88×10² N/m
pH7±2
Moisture≤14%
Core-Making SpeedAbout 10–200 m/min
Facing Line SpeedAbout 4–30 m/min
Packaging25 kg bags
GradesCore-strip; facing/lamination
Facing, Water Only25 kg powder + 30–40 kg room-temperature water; stir about 30 minutes
Facing, With Starch25 kg powder + 40–60 kg room-temperature water, two tanks; starch and filler weights confirmed separately
